COPPIA DI SERRAGGIO
CONICA GAS BSPT ISO 7 & NPT ANSI B 1.20.1
FILETTO | 1/8" | 1/4" | 3/8" | 1/2" | 1/8" npt | 1/4" npt | 3/8" npt | 1/2" npt |
Nm | 10-12 | 14-16 | 16-18 | 18-20 | 3,5 | 4,5 | 7 | 12 |
FILETTO | M5x0,8 | M7x1,0 | 1/8" | 1/4" | 3/8" | 1/2" |
Nm | 1 | 3 | 6 | 7,5 | 9 | 9 |
