OXYGEN HOSE/20 ISO 3821 BLUE
ONLINE CATALOGUE › HOSES › Flexible pipes for technical gases
Download sheet in pdf format
Rubber hose for oxygen delivery at a maximum pressure of 20 bar for autogenous welding torches. Flexible and lightweight, resistant to backfires.
Smooth black SBR tube. Smooth blue EPDM coating.
Internal reinforcement armor with synthetic thread.
Approvals: ISO 3821
Operating pressure 20 bar – burst 60 bar.
Operating temperature: -25° +80°C
50-100 meter rolls
External marking with name, operating pressure and production date.
The tube does not expire!
Smooth black SBR tube. Smooth blue EPDM coating.
Internal reinforcement armor with synthetic thread.
Approvals: ISO 3821
Operating pressure 20 bar – burst 60 bar.
Operating temperature: -25° +80°C
50-100 meter rolls
External marking with name, operating pressure and production date.
| ITEM | Dimensions | Weight Kg/m | Rolls m |
|---|---|---|---|
| 02OEN06/13 | 6x13 | 0.16 | 50/100 |
| 02OEN0008/15 | 8x14 | 0.18 | 50/100 |
| 02OEN0009/16 | 9x16 | 0.20 | 50/100 |
| 02OEN0010/17 | 10x17 | 0.21 | 50/100 |
| 02OEN0013/23 | 13x23 | 0.40 | 50/100 |
| 02OEN0019/30 | 19x30 | 0.62 | 50/100 |
| 02OEN0025/37 | 25x30 | 0.86 | 50/100 |
The tube does not expire!
