Item number | Dimension Ø mm | Weight gr/m | Curvature radius mm | Operating pressure bar | Rolls m |
---|---|---|---|---|---|
04PLIQ0000025 | 25 | 500 | 100 | 7 | 50 |
04PLIQ0000032 | 32 | 600 | 130 | 6 | 50 |
04PLIQ0000038 | 38 | 700 | 150 | 6 | 50 |
04PLIQ0000040 | 40 | 800 | 160 | 6 | 50 |
04PLIQ0000045 | 45 | 900 | 180 | 5.5 | 50 |
04PLIQ0000050 | 50 | 1050 | 200 | 5 | 50 |
04PLIQ0000060 | 60 | 1250 | 240 | 4.5 | 50 |
04PLIQ0000063 | 63 | 1390 | 240 | 4.5 | 50 |
04PLIQ0000070 | 70 | 1550 | 280 | 4 | 50 |
04PLIQ0000076 | 76 | 1700 | 300 | 4 | 50 |
04PLIQ0000080 | 80 | 1850 | 320 | 3.5 | 30 |
04PLIQ0000090 | 90 | 2250 | 360 | 3.5 | 30 |
04PLIQ0000102 | 102 | 2700 | 400 | 3 | 30 |
04PLIQ0000110 | 110 | 3100 | 440 | 3 | 30 |
04PLIQ0000120 | 120 | 3600 | 480 | 2.5 | 20 |
04PLIQ0000125 | 125 | 3900 | 510 | 2.5 | 20 |
04PLIQ0000130 | 130 | 4100 | 520 | 2.5 | 20 |
04PLIQ0000152 | 152 | 5000 | 610 | 2 | 20 |
04PLIQ0000160 | 160 | 5600 | 640 | 2 | 20 |
04PLIQ0000200 | 200* | 10000 | 800 | 1.5 | 10 |
