SMOOTH INTERNAL AND EXTERNAL SURFACES
FLEXIBILITY
Internal Ø | External Ø | Press. exercise at 23 °C | Press. burst at 23 °C | Curvature radius | Weight meter | Length roll |
mm | mm | Cafe | Cafe | mm | g/m | m |
10 | 15 | 8 | 24 | 54 | 125 | 50 |
12 | 16.5 | 6 | 18 | 90 | 115 | 50 |
13 | 18 | 8 | 24 | 64 | 155 | 50 |
13 | 19 | 8 | 24 | 78 | 180 | 50 |
15 | 18.5 | 6 | 18 | 52 | 135 | 50 |
16 | 21 | 8 | 24 | 96 | 190 | 50 |
16 | 22 | 8 | 24 | 90 | 230 | 50 |
18 | 23.4 | 6 | 18 | 95 | 230 | 50 |
19 | 25 | 7 | 21 | 100 | 275 | 50 |
19 | 26 | 7 | 21 | 105 | 310 | 50 |
22 | 29 | 7 | 21 | 370 | 50 | |
25 | 32 | 6 | 18 | 400 | 50 | |
25 | 33 | 6 | 18 | 310 | 460 | 50 |
30 | 38 | 6 | 18 | 560 | 50 | |
35 | 43 | 5 | 15 | 700 | 50 | |
40 | 49 | 4 | 12 | 525 | 840 | 50 |
50 | 60 | 4 | 12 | 1300 | 25 |
