Articolo | Dimensione Ø inch | Dimensione Ø mm | Peso gr/m | Raggio di curvatura mm | Pressione esercizio bar | Rotoli m |
---|---|---|---|---|---|---|
04PARI0000025 | 1" | 25 | 500 | 100 | 7 | 50 |
04PARI0000032 | 1 1/4" | 32 | 600 | 130 | 6 | 50 |
04PARI0000038 | 1 1/2" | 38 | 700 | 150 | 6 | 50 |
04PARI0000040 | 40 | 740 | 160 | 6 | 50 | |
04PARI0000045 | 1 3/4" | 45 | 900 | 180 | 5,5 | 50 |
04PARI0000050 | 2" | 50 | 1050 | 200 | 5 | 50 |
04PARI0000060 | 60 | 1250 | 240 | 4.5 | 50 | |
04PARI0000063 | 2 1/2" | 63 | 1390 | 250 | 4.5 | 50 |
04PARI0000075 | 75 | 1700 | 300 | 4 | 30 | |
04PARI0000076 | 3" | 76 | 1700 | 300 | 4 | 30 |
04PARI0000080 | 80 | 1850 | 320 | 3,5 | 30 | |
04PARI0000089 | 3 1/2" | 89 | 2250 | 360 | 3,5 | 30 |
04PARI0000090 | 90 | 2250 | 360 | 3,5 | 30 | |
04PARI0000100 | 100 | 2700 | 400 | 3 | 30 | |
04PARI0000102 | 4" | 102 | 2700 | 400 | 3 | 30 |
04PARI0000110 | 110 | 3100 | 440 | 3 | 20 | |
04PARI0000120 | 120 | 3600 | 480 | 2,5 | 20 | |
04PARI0000125 | 125 | 3900 | 500 | 2,5 | 20 | |
04PARI0000127 | 5" | 127 | 3900 | 500 | 2,5 | 20 |
04PARI0000130 | 130 | 4100 | 520 | 2,5 | 20 | |
04PARI0000150 | 150 | 4200 | 600 | 2 | 20 | |
04PARI0000152 | 6" | 152 | 5000 | 610 | 2 | 20 |
04PARI0000160 | 160 | 5600 | 640 | 2 | 20 | |
04PARI0000200 | 200 | 9500 | 800 | 1,5 | - | |
04PARI0000203 | 8" | 203 | 9500 | 800 | 1,5 | - |
04PARI0000254 | 10" | 254 | 13500 | 1000 | 1,5 | - |
04PARI0000304 | 12" | 304 | 18000 | 1200 | 1,5 | - |
