Code | Dimensions Ø mm | Curvature radius mm | Working pressure bar | Theoretical weight Kg/m |
---|---|---|---|---|
10GBIBLU6009/16 | 9x16 | 50 | 25 | 0.21 |
10GBIBLU6012/21 | 12x21 | 70 | 20 | 0.29 |
10GBIBLU6015/23 | 15x23 | 90 | 20 | 0.37 |
10GBIBLU6015/25 | 15x25 | 120 | 20 | 0.43 |
10GBIBLU6019/30 | 19x30 | 120 | 20 | 0.52 |
10GBIBLU6022/30 | 22x30 | 180 | 15 | 0.40 |
10GBIBLU6025/34 | 25x34 | 200 | 15 | 0.50 |
10GBIBLU6030/42 | 30x42 | 240 | 15 | 0.82 |
10GBIBLU6038/52 | 38x52 | 280 | 20 | 1.10 |
10GBIBLU6040/54 | 40x54 | 300 | 20 | 1.20 |
10GBIBLU6045/60 | 45x60 | 340 | 15 | 1.45 |
10GBIBLU6050/68 | 50x68 | 330 | 15 | 2.00 |
10GBIBLU6060/78 | 60x78 | 480 | 15 | 2.40 |
