HOSE FOR PRESSURE WASHERS



Download sheet in pdf format
Flexible rubber hose with double metal braid incorporated for reinforcement.
Smooth internal surface and external canvas impression, temperature resistant rubber underlayer. Micro-perforated synthetic rubber cover resistant to atmospheric agents and abrasion, black or stain-resistant blue on request.
Supplied with pre-assembled fittings by pressing, with anti-heat rubber sleeves at the end.
Usage: Passage of hydraulic, mineral and biological oils, especially used for water or water-emulsified oil mixtures.

Standard lengths available: 10 – 15 – 20 metres.
Operating temperature: -10° +155° C.


Dimension Ø mm Bar working pressure Burst pressure Bar Curvature radius mm Weight Kg/m
6 - 1/4" 400 1600 75 0.29
8 - 5/16" 400 1600 85 0.35
10 - 3/8" 400 1600 90 0.46
12 - 1/2" 300 1200 130 0.51
