Code | OR mm | Pressure of exercise Bar | Pressure of explosion Bar | radius of curvature mm |
---|---|---|---|---|
03PE000002/04 A | 2X4 | 18.5 | 75 | 20 |
03PE000003/05 A | 3X5 | 12.5 | 50 | 30 |
03PE000004/06 A | 4X6 | 10 | 40 | 40 |
03PE004.35/6.35 A | 4.35x6.35 | 9 | 36 | 50 |
03PE000006/08 A | 6X8 | 7.5 | 30 | 50 |
03PE06,36/9,54 A | 6.35x9.52 | 10 | 40 | 100 |
03PE000008/10 A | 8X10 | 6 | 25 | 120 |
03PE000008/12 A | 8X12 | 7.5 | 30 | 160 |
03PE000009/12 A | 9x12 | 7.5 | 30 | 120 |
03PE000010/12 A | 10x12 | 5 | 20 | 120 |
