Imperial stainless steel pipe connection fitting with NPT female thread
Minimum package 10 pieces.



Code
diameter
Tube
fillet steak
internal hole
fitting
mm
NPT
mm
SCBF-2-2N
1/8"
1/8"
2.28
SCBF-4-2N
1/4"
1/8"
4.82
SCBF-4-4N 1/4" 1/4" 4.82
SCBF-6-4N 3/8 1/4 7.11
SCBF-6-6N 3/8" 3/8" 7.11
SCBF-8-6N 1/2" 3/8" 10.41
SCBF-8-8N 1/2" 1/2" 10.42
SCBF-12-12N 3/4 3/4" 15.74
SCBF-16-16N 1" 1" 10.35pm
SCBF-16-20N 1"1/4 1"1/4 27.68
SCBF-20-24N 1"1/2 1"1/2 34.03
SCBF-32-32N 2" 2" 45.97
