TRELLFLEX OIL VR COMPOSITE HOSE
ONLINE CATALOGUE › HOSES › PIPES suitable for ATEX environment
Download sheet in pdf format
MULTI-PURPOSE flexible hose for the suction and delivery of VAPORS of highly aggressive chemical products. Reference standard: BS 5842 on request produced according to EN 13765 and TMD STANDARDS.
ADVANTAGES: exceptionally flexible and easy to handle, use in environments subject to ATEX regulations thanks to the electrical conductivity ensured by the two steel coils <1.0O/m
USES: Suction of gases, petroleum products and derivatives with an aromatic content of up to 100% in industrial plants, tankers, depots. Supplied in use sizes.
STRUCTURE: composed of layers of PTFE film compressed between two galvanized steel spirals.
External covering in yellow PVC-coated polyester canvas, wavy appearance with visible metal spiral.
Maximum suction 0.9 bar (approximately empty).
Operating temperature: -30° +80° C.
Supplied exclusively with assembled fittings in aluminium, brass, polypropylene, stainless steel.
ADVANTAGES: exceptionally flexible and easy to handle, use in environments subject to ATEX regulations thanks to the electrical conductivity ensured by the two steel coils <1.0O/m
USES: Suction of gases, petroleum products and derivatives with an aromatic content of up to 100% in industrial plants, tankers, depots. Supplied in use sizes.
STRUCTURE: composed of layers of PTFE film compressed between two galvanized steel spirals.
External covering in yellow PVC-coated polyester canvas, wavy appearance with visible metal spiral.
Maximum suction 0.9 bar (approximately empty).
Operating temperature: -30° +80° C.
Supplied exclusively with assembled fittings in aluminium, brass, polypropylene, stainless steel.
| Dimension Ø mm | Bar working pressure | Burst pressure bar | Curvature radius mm | Weight kg/m | Length maximum production m |
|---|---|---|---|---|---|
| 50x62 | 7 | 28 | 180 | 1.55 | 30 |
| 65x78.5 | 7 | 28 | 200 | 2.51 | 30 |
| 80x95 | 7 | 28 | 280 | 2.88 | 30 |
| 100x118 | 7 | 28 | 400 | 4.70 | 20 |
| 125x149 | 7 | 28 | 450 | 8.16 | 15 |
| 150x180 | 7 | 28 | 710 | 10.80 | 20 |
| 200x234 | 7 | 28 | 740 | 5.60pm | 20 |
