Standard hose for roadside distributors of service and self-service stations for dispensing diesel, BIOFUEL, SUPER LEAD-FREE. Good resistance to aging and abrasion due to dragging.
Approval Standards: EN1360:2013 TYPE1

TUBE: smooth black NBR resistant to hydrocarbons - oilproof
ANTISTATICITY: conductor R<10 6 O/m Image results for ATEX LOGO
WEAVE: textile braid
COVER: smooth black NBR/PVC rubber compound
TEMPERATURE: -30° + 55° C
Black colour
WORKING PRESSURE: 16 Bar
BURST PRESSURE: 48 Bar

COLORED RUBBER HOSE ON REQUEST: blue, red or green.

Codes OR
mm
Radius of curvature
mm
06GB18016/025 L 16x25 80
06GB18019/031 L 19x31 100
06GB18025/037 L 25x37 140
