VENABIO FLOW pumpgrade

For applications where small flow variations and long pump life are of the utmost importance and a hose of minimum hardness is recommended.

DESCRIPTIONS
Silicone hose is the basic material for every single process use.
Its excellent general performance and resistance to temperature, humidity, ozone and steam and high biocompatibility make it the preferred product in all phases of bioprocessing, from drug formulation, upstream processing to all critical phases both downstream of separation and at final filling.

Platinum cured silicone tube .
Postcured to completely eliminate volatile substances
Shore A hardness 50
Tensile strength N/mm2 >7
Elongation % >350
Tear resistance kN/m >20
Density g/cm3 1.13
Operating temperature: -60°+220°C

LASER ENGRAVING: Traceable with reference, batch number and ID/OD
RADIO-STABILIZED: Gamma beam(s) available
PACKAGING: Double vacuum bagged
ANIMAL FREE: free of animal-derived components
CLEAN ROOM STERILIZATION: Manufactured in ISO14644-1 Class 7
SMOOTHNESS: Reduces protein binding and biofilm formation
ROLL LENGTH: Available in 50 feet and 100 feet (15m - 30m approx)
AVAILABLE INTERNAL DIAMETERS: from 0.80 mm (1/32") to 25.40 (1")

reference standards
ADCF
P/BPA
BSE/TSE
EU 10/2011
EU 1935/2004
BfR XV
3A 18-0
PE 3.1.9.
FDA 21CFR177.2600
USP 85
USP87
USP88
USP381
USP788
ISO 10993-4
ISO 10993-5
ISO 10993-6
ISO 10993-10
ISO 10993-11
Removable and releasable

POSSIBLE STERILIZATIONS
Dry heat
Autoclave
CIP
SIP
Ethylene oxide
Hydrogen peroxide
and Beam (25 kGy)
Gamma (25kGy)
