Code | Diameters interior mm | Operating pressure Cafe | Depression Cafe | Radius of curvature mm | weight g/m |
---|---|---|---|---|---|
11PVPUR000040 | 40 | 0.70 | 0.35 | 25 | 270 |
11PVPUR000050 | 50 | 0.60 | 0.30 | 30 | 340 |
11PVPUR000060 | 60 | 0.50 | 0.25 | 40 | 420 |
11PVPUR000070 | 70 | 0.45 | 0.22 | 45 | 480 |
11PVPUR000080 | 80 | 0.40 | 0.15 | 50 | 550 |
11PVPUR000100 | 100 | 0.30 | 0.14 | 65 | 680 |
11PVPUR000120 | 120 | 0.25 | 0.12 | 75 | 770 |
11PVPUR000130 | 130 | 0.25 | 0.10 | 85 | 910 |
11PVPUR000150 | 150 | 0.15 | 0.08 | 100 | 1050 |
11PVPUR000160 | 160 | 0.15 | 0.08 | 105 | 1120 |
11PVPUR000180 | 180 | 0.12 | 0.06 | 120 | 1200 |
11PVPUR000200 | 200 | 0.10 | 0.06 | 130 | 1370 |
11PVPUR000250 | 250 | 0.06 | 0.04 | 165 | 1660 |
11PVPUR000300 | 300 | 0.04 | 0.03 | 200 | 2050 |
11PVPUR000350 | 350 | 0.03 | 0.02 | 235 | 2380 |
11PVPUR000400 | 400 | 0.02 | 0.02 | 270 | 2720 |
11PVPUR000450 | 450 | 0.01 | 0.01 | 300 | 3040 |
11PVPUR000500 | 500 | 0.01 | 0.01 | 350 | 3640 |
