SAFETY CLAMP EN 14420-3 COLORED ALUMINUM
ONLINE CATALOGUE › CLAMPS AND TIGHTENING SYSTEMS › SAFETY CLAMP - SPANNLOC
Download sheet in pdf format
Safety clamp type "SPANNLOC" according to the STANDARD EN 14420-3 in Aluminium
Galvanized steel screws
Maximum working pressure: 25 bar
Closing range compatible with the external diameter of the tube
Attention!
The seal is guaranteed only when tightening to smooth pipes on the outside or on any smooth sleeves at the ends.
AVAILABLE COLORS: BLUE - RED - BLACK - WHITE - YELLOW
Galvanized steel screws
Maximum working pressure: 25 bar
Closing range compatible with the external diameter of the tube
Attention!
The seal is guaranteed only when tightening to smooth pipes on the outside or on any smooth sleeves at the ends.
AVAILABLE COLORS: BLUE - RED - BLACK - WHITE - YELLOW
| dn | pressure maximum | field of closure | screws |
| 19 | 25 | 30-33 | M6x20 |
| 25 | 25 | 36-39 | M6x20 |
| 32 | 25 | 43-46 | M6x20 |
| 38 | 25 | 50-53 | M6x20 |
| 50 | 25 | 63-67 | M8x25 |
| 75 | 25 | 89-93 | M8x25 |
